Glycerin-filled glasses feature electronic autofocus

Glycerin-filled glasses feature electronic autofocus
Carlos Mastrangelo (right) and Nazmul Hasan with the prototype glasses
Carlos Mastrangelo (right) and Nazmul Hasan with the prototype glasses
View 2 Images
Carlos Mastrangelo (right) and Nazmul Hasan with the prototype glasses
1/2
Carlos Mastrangelo (right) and Nazmul Hasan with the prototype glasses
A rechargeable battery in a commercial version of the specs should be good for over 24 hours of use
2/2
A rechargeable battery in a commercial version of the specs should be good for over 24 hours of use

It can be a hassle, taking your glasses on and off to switch between near and distant vision. There are bifocals, of course, plus there are now glasses on which you can adjust the focus. Scientists from the University of Utah, however, have gone one better – they've developed glasses that change focus automatically, depending on what you're looking at.

Created by a team led by Prof. Carlos Mastrangelo and doctoral student Nazmul Hasan, the glasses feature "liquid lenses" that change shape.

Each lens is made up of two clear rubber membranes – one in the front and one in the back – with a layer of clear viscous glycerin sandwiched between them. Three mechanical actuators push the rear membrane in and out, compressing or releasing the glycerin and thus changing the curvature of the lens. This, in turn, changes its focal length.

It's not unlike the technology utilized in the Adlens adjustable-focus glasses, although they're operated manually. By contrast, the Utah glasses incorporate an electronic distance meter in the bridge, which uses pulses of infrared light to determine how far away objects are from the eyes. Whenever that distance changes, it instructs the actuators to reshape the lenses accordingly. They do so in a claimed 14 milliseconds.

A rechargeable battery in a commercial version of the specs should be good for over 24 hours of use
A rechargeable battery in a commercial version of the specs should be good for over 24 hours of use

The first time that a person uses the glasses, they calibrate them to their optical prescription via Bluetooth using a smartphone app. From that point on, they only need to recalibrate them as their prescription changes.

According to Mastrangelo, a rechargeable battery in a commercial version of the specs should be good for over 24 hours of use. That final version of the glasses – which will be considerably lighter and less bulky than the current prototype – may be commercially available within three years. The technology is currently being developed by spinoff company Sharpeyes.

A paper on the research was recently published in the journal Optics Express.

Source: University of Utah

4 comments
4 comments
Bob Flint
Interesting concept has been around for awhile but the real world issues such as reliability of vision during critical functions such as driving, or even just walking up or down stairs, and the systems ability to cope with sudden temperature changes will be questions to answer....
Will most definitely need to be better looking more compact, & as always the cost...
RSnyder
Distance vision through a window. Which distance do the glasses adjust to? The window, or the object past the window?
asninsp
How are these glasses better than having an artificial lens implant?
You don't have to wear anything, no batteries to charge, no recalibration ... it's just a good idea too late.
Augure
@asninsp, the difference is this is science fiction.
