World record Internet data transfer rate almost 50,000 times faster than broadband

Using advanced digital signal processing techniques, researchers have created an optical data transmission system able to transfer information at a rate of 1.125 terabits per second
Using advanced digital signal processing techniques, researchers have created an optical data transmission system able to transfer information at a rate of 1.125 terabits per second
View 1 Image
Using advanced digital signal processing techniques, researchers have created an optical data transmission system able to transfer information at a rate of 1.125 terabits per second
1/1
Using advanced digital signal processing techniques, researchers have created an optical data transmission system able to transfer information at a rate of 1.125 terabits per second

At a blistering 1.125 terabits per second, a new optical communication system developed by University College London (UCL) researchers has created a new record for the fastest ever data transfer rate for digital information. At the quoted rate, say the researchers, the entire HD series of the TV show Game of Thrones could be downloaded in less than one second.

To help achieve these incredibly fast transfer rates, the researchers took recent developments fromthe realm of information theory in regard to the maximum amount of information that can be transmitted being limited by the finite signal-to-noise ratio (SNR), and applied advanced digital signal processing techniques to optimize the SNR and maximize data throughput.

In other words, the team determined the most efficient way to encode data in optical signals, taking into account the limitationsof the transmitter and receiver. They then cleverly used noise reduction techniques normally found in wireless communications and applied them to optical transmission. In this way, the team was able to ensure that the transmitted signals were able to be minimally effected by distortions inthe system electronics.

"While current state-of-the-art commercial optical transmissionsystems are capable of receiving single channel data rates of up to 100 gigabitsper second, we are working with sophisticated equipment in our lab todesign the next generation core networking and communications systems that canhandle data signals at rates in excess of 1 terabit per second," said Lead researcher, Dr Robert Maher, of UCL Electronic & ElectricalEngineering. "For comparison this is almost 50,000 times greater than the average speed of a UK broadband connectionof 24 megabits per second, which is the current speed defining"superfast" broadband."

Building on previous work, where the team transmitted optical signals over a world-record 5,890 km (3,660 mi) error-free, the new system employs a total of fifteen separate data transmission channels, with each carrying an encoded optical signal of different wavelengths. Modulated using the 256QAM format normally employed in cablemodems, the 15 signals were combined and then sent to a single optical receiver for detection. In this way, by arraying the transmission channels, the researchers created a "super-channel" that they believe may form the basis for future high-capacitycommunication systems.

"Using high-bandwidthsuper-receivers enables us to receive an entire super-channel in one go," said Dr Maher. "Super-channels are becoming increasingly important for core opticalcommunications systems, which transfer bulk data flows between large cities,countries or even continents. However, using a single receiver varies thelevels of performance of each optical sub-channel so we had to finely optimizeboth the modulation format and code rate for each optical channel individuallyto maximize the net information data rate. This ultimately resulted in usachieving the greatest information rate ever recorded using a single receiver."

Though initial research has been conducted with the transmitter feeding directly to the receiver in order to realize the maximum data transfer rate, the team now intends to run the system with long cable lengths. In this way, performance tests will be conducted to measure the achievable data rates over long distances where distortion is introduced by the optical cables themselves.

The results of this research were recently published in the Nature journal Scientific Reports.

Source: University College London

8 comments
Daishi
There are networks that are over 1Tbps today but they are DWDM using multiple superchannels. These are often modulated in BPSK or QPSK but 256QAM would be a significant leap if it could be achieved at range but it's pretty unlikely. Shannon's theorem is often used to calculate maximum data throughputs in RF based on channel bandwidth and SNR but optical fiber is generally considered to be different as the sources of "noise" are different (ie the photons themselves) but you still have things like noise, microflections, and dispersion to contend with. Infinera did some testing last year and was able to get between 400 and 1,200 kilometers with 16QAM but over 1,800 kilometers reliably with 8QAM: http://blog.infinera.com/2015/03/17/the-8qam-sweet-spot/ It's cool to see there is still a steady roadmap of improvements to data rates that are possible over a single strand of glass. They are mostly needed for streaming video at 4k bitrates at scale.
BZD
Arrrgh. Why is it that every time there is a record in either storage or transmission of data the numbers are quantified with something meaningless. Statements like "...the entire HD series of the TV show Game of Thrones could be downloaded in less than one second" are as accurate as someone saying the caught a fish the length of a rubber band. It would have been just as meaningful saying data is transferred very, very fast. How much data video in HD takes up is hugely dependent on the format, the compression ratio, the type of audio and so on. And while I am at it on the silliness. Is a UK broadband connection of 24 Mbps somehow different to say a German broandband connection of 24 Mbps? :-)
gr000
Are we talking about 1.125 TeraBYTES per second here (TBps) or TeraBITS per second (Tbps)?
Stephen N Russell
How soon can this apply to servers & or home PCs alone?
Knut
Most of the data backbone use STM256 or twice of this, using DWDM and "Segments" of 2Gbps as STM segments. So Stephen, it is commercially available outside the US. Regarding broadband speed, the UK is still US "broadband" territory while Germany is fibre - so that comparison holds - about 1000 times what I have to the wall. I would investigate KTH in Stockholm, where they have made new laser technology that is needed for this capacity. The research is then sponsored by Ericsson. The STM will use inference between segments to transmit the signalling. As long as it is impossible to route IP packets at this speed, the use of the capacity is to multiplex many IP transmissions - not to transfer a movie, but 1000 movies simultaneously. Using the fibre this way makes it impossible to intercept the signals on it like Snowden claims the NSA does. This is only possible on US SONET technology.
StWils
I am tired of hearing about tremendous speed and capacity increases coupled with equally tremendous cost reductions when the Dishonest Lying Ba$tards running these businesses only increase prices and not speed, capacity, and stability. Somehow the DLBs never seem to be able to lower prices even though the number of customers and data volume steadily rises.
Daishi
@Stephen This technology is more about aggregating lots of people at the core. It's not really intended as a "last mile" technology. Last mile technologies you will see are EPON, 10G-EPON etc. For context over a 1G pipe you can stream different movies to almost 70 4k TV's all at the same time. @Knut People are mostly moving away from SONET over to ethernet. @StWils In general $cost/bit is improving but growth is still outpacing it. Most the companies involved are indeed crappy but that fundamental is hard to get around.
MattIsley
What about this: http://www.extremetech.com/extreme/192929-255tbps-worlds-fastest-network-could-carry-all-the-internet-traffic-single-fiber?
