World's whitest paint is now thin enough to coat cars and planes

World's whitest paint is now thin enough to coat cars and planes
Creators of the world's whitest paint hope to soon apply it to planes and cars
Creators of the world's whitest paint hope to soon apply it to planes and cars
View 3 Images
Creators of the world's whitest paint hope to soon apply it to planes and cars
1/3
Creators of the world's whitest paint hope to soon apply it to planes and cars
The new version of the world's whitest paint seen on the right, compared to the thicker, previous iteration on the left
2/3
The new version of the world's whitest paint seen on the right, compared to the thicker, previous iteration on the left
Study author Xiulin Ruan with his lab’s sample of the whitest paint on record
3/3
Study author Xiulin Ruan with his lab’s sample of the whitest paint on record
View gallery - 3 images

Last year, engineers at Purdue University used their expertise in materials science to produce the world’s whitest paint, with an ability to reflect around 98% of incoming sunlight and therefore holds great potential when it comes to energy efficiency for buildings. The team has now made some tweaks to the recipe and produced a version that is thinner and lighter, which they say is ideal for use on cars, trains and planes.

The original version of the ultra-white paint owed its supreme ability to reflect sunlight to the inclusion of barium sulfate, a chemical compound used in photographic paper and cosmetics. This was added to the mix in the form of particles of different sizes with varying ability to scatter light, enabling the paint to bounce away more of the spectrum of incoming sunlight.

With a reflectivity of 98.1%, the material far exceeded the reflectivity of commercially available heat-reflecting paints that boast 80 to 90% reflectivity. In tests on outdoor surfaces, the team found the paint could significantly lower their temperature compared to the ambient surrounds and could potentially produce cooling effects that are on par with common air conditioners. But the paint did have its shortcomings.

“To achieve this level of radiative cooling below the ambient temperature, we had to apply a layer of paint at least 400 microns thick,” said Xiulin Ruan, who developed the paint. “That’s fine if you’re painting a robust stationary structure, like the roof of a building. But in applications that have precise size and weight requirements, the paint needs to be thinner and lighter.”

So Ruan and his team came up with a new recipe. The new material features boron nitride in hexagonal nanoplatelet form and offers a solar reflectance of 97.9%, so a touch below the original, but does so in layers of just 150 microns thick. This new paint is not only thinner, but is also lower density and therefore weighs around 80% less.

The new version of the world's whitest paint seen on the right, compared to the thicker, previous iteration on the left
The new version of the world's whitest paint seen on the right, compared to the thicker, previous iteration on the left

“This light weight opens the doors to all kinds of applications,” said George Chiu, a Purdue professor of mechanical engineering. “Now this paint has the potential to cool the exteriors of airplanes, cars or trains. An airplane sitting on the tarmac on a hot summer day won’t have to run its air conditioning as hard to cool the inside, saving large amounts of energy. Spacecraft also have to be as light as possible, and this paint can be a part of that.”

The scientists say they are currently in discussions to commercialize their paint and, having filed patents for the technology, are enthusiastic about the possibilities.

“Using this paint will help cool surfaces and greatly reduce the need for air conditioning,” Ruan said. “This not only saves money, but it reduces energy usage, which in turn reduces greenhouse gas emissions. And unlike other cooling methods, this paint radiates all the heat into deep space, which also directly cools down our planet. It’s pretty amazing that a paint can do all that.”

The research was published in the journal Cell Reports Physical Science

Source: Purdue University
